PSR Class Legal 6275G

Please note, T51R housing option requires an extra 7 days handling time
PSR Class Legal Turbo with 62/98mm Compressor wheel
Dual ceramic ball bearing system provides optimal turbo response &
better durability by reducing the shaft-motion
10 Blade G-Aero billet compressor wheel with extended tapered tip technology
9 Blade G-Aero Inconel 713c turbine wheel
Anti-Surge ported-shroud compressor inlet, cover with integrated speed sensor port
7 Turbine housing options available
SPEC

-Compressor Wheel: 62*98mm

-Turbine Wheel: 82*75mm

-Compressor Inlet: 5? Hose

-Compressor Outlet: 3? V-Band

-Turbine Inlet: 3? V-Band

-Turbine Outlet: 3.5? V-Band

-Water Ports: -6AN

-Oil Feed: Flange Required(Recommended size: -4AN Std T4 Flange Non-Restricted)

-Oil Drain: Angle 15?, -12AN(O-Ring sealed Flange Kit Incl?)

A 4″ turbine outlet adapter flange is also available , please contact us at time of ordering if this is required.

It’s strongly recommended to run water cooling to aid reliability (needed for warranty)
